Syslog

Introduction

The DB CyberTech platform uses syslog to provide event reporting that can be directed to a central Security Information and Event Management (SIEM) system as well as reporting general system health information. Syslog output is encoded in the Common Event Format (CEF), which allows easy integration into a number of common security information and event management (SIEM) and log-analysis tools. DB CyberTech can provide sample integration with popular tools.

This manual describes the DBC platform syslog messages.

Organization of the Manual

This manual contains the following chapters:

  • Message Overview

This chapter describes the format of the DBC platform syslog messages, along with the signature ID and name values

  • Platform Syslog Messages

This chapter describes the DBC platform syslog messages and provides message examples.

Changes in This Revision

  • Updated example messages

Message Overview
This chapter describes the format of the messages that the DBC platform generates to syslog. It also describes the signature ID and name values.

Syslog Message Format

Syslog messages forwarded from the DBC platform are formatted to meet the CEF specification.

Syslog Message Format

CEF Header Field Platform Data
Version 0
Device Vendor DB Networks
Device Product DBN
Device Version Current system version
Signature ID Numeric ID, see below for detailed information
Name String name associated with Signature ID
Severity Value from 0 to 7, system specified
cs1Label System identifier
cs1 System serial number (found in admin > About in the web management interface)
system_identifier System serial number (found in admin > About in the web management interface)
rt Current timestamp in milliseconds since epoch.
Event specific data Varies by event

Signature ID and Name Values

Syslog Message Signatures

Signature ID Name Description
0 distinct_event New system events
1 repeat_event A count, with detail, of repeated events
2 heart_beat Used in version 1.0 – 1.3 to report system health
3 engine_start A system has powered up or restarted
4 archive Indicates status of overnight system archive tool
5 dbfw_gc Indicates a system restart due to an overload of data
6 mds_new_user A new user identified by the system
7 mds_new_service A new service identified by the system
8 mds_new_host A new host identified by the system
9 mds_new_listener A new listener identified by the system
10 tally_new_ipseity A new context is identified by the system
11 cnt External counter dump
12 sys Health data
13 slowsys Health data
14 dbfwsys Health data
15 internal Internal debug use
16 cnta Full counter dump (much lower frequency)
17 dbhealth Database health status in CSV format
18 it_clustered_flow Issued when the autopilot adds a data flow to the incident domain to be clustered with other behavioral incident data flows
19 upgrade System upgrade logs
20 audit System audit logs
21 dbdu Postgres table disk usage
22 it_new_cluster Issued each time the system creates a new incident
23 it_obsolete_cluster Issued when regrouping occurs, or the user introduces either learning or policy constraints into the system, incident clusters of data flows can become obsolete
24 it_cluster_activity Issued when data flows that had been clustered into an incident now exhibit activity (that is, executing SQL statements)
25 it_auto_learned Issued when a data flow is learned by the autopilot, using the same fields as the ITClusteredFlow event except clusterId
26 it_policy_activity Issued when data flows matching a committed policy constraint with a syslog category action exhibit activity (that is, they execute SQL statements)
27 it_new_context Issued when a new context or session is observed
28 it_new_access Issued when a given user role database object access or changes another database object
29 it_new_flow Issued when a new data flow is observed

Platform Syslog Messages
This chapter describes the DBC platform syslog messages.
Note Note: The default size of the rsyslog is 8K. Logs that exceed this size are truncated automatically. If you expect syslog messages greater than 8K, increase the default message size to avoid truncation.

Engine Restart Message

The restart message reports the startup of the platform. This message indicates that the Platform has completed its power up sequence after an initial power-up, restart/reset, or fatal error. If this message is detected and no intentional restart was initiated, contact customer service to investigate the cause.

A typical engine restart message resembles the following:

<133>2018-06-11T12:39:03.984166-05:00 dbfw dbn: CEF:0|DB Networks|DBN|5.3.7|3|engine_start|5| cs1Label=system identifier cs1=FW42-ED-VV-B-0423 system_identifier=FW42-ED-VV-B-0423

The message is identified by Signature ID=3 and name=engine_start.

Event Report Messages

Event report messages are generated as soon as an event is detected.

There are two types of event report messages:

  • distinct_event messages pertain to new unique SQL statements that are detected as possible threats. Distinct events have a Signature ID=0 and name=distinct_event.

  • repeat_event messages represent repeated executions of previously detected SQL statements. Repeat events have a Signature ID=1 and name=repeat_event.

Both messages contain the same information but are distinguished by the labels above appearing in the Name field of the CEF prefix.

A typical distinct_event resembles the following. A repeat_event has the same structure, but the cnt field is greater than 1.

\<132>2018-06-11T16:28:53.769474-05:00 dbfw dbn: CEF:0|DB Networks|DBN|5.3.7|0|distinct_event|10| cs1Label=system identifier cs1=FW42-ED-VV-B-0423 system_identifier=FW42-ED-VV-B-0423 externalId=23179 cnt=1 rt=1528752533769 start=1449230398145 destinationServiceName=accounts cn1Label=statement identifier

cn1=22932 statement_identifier=22932 cat=structural dst=10.4.40.7 dpt=1433 src=10.15.32.25 spt=37224 cs2Label=score cs2=1.000 score=1.000 cs3Label=confidence cs3=certain confidence=certain act=exec_dispatch target_sql_id=320

The first part of the message contains the elements of the standard CEF format.

Event Report Message Field Descriptions

Field Description
externalId Unique event id used to look the event up in the DBN event log.
cnt Number of occurrence of events with this statement identifier. There will always be one for distinct events.
rt Transmit time of the event.
start Epoch time, in milliseconds, of the event.
destinationServiceName Name of the database associated with the attack.
cn1Label Statement identifier.
cn1 Unique statement Identifier, also known as the sqlId, used to look up the event in the DBN event log.
cat Type of event (structural or parametric).
dst Destination IP address of the database involved in the event.
dpt Destination port of the database involved in the event.
src Source IP address of the client involved in the event.
spt Source TCP port of the client involved in the event.
cs2Label Score.
cs2 Numerical confidence score (0.0 – 1.0)
cs3Label Confidence.
cs3 String confidence (certain, overwhelming, likely, suspicious, possible).
act Type of action involved in the event (maps to protocol RPC).
target_sql_id Integer value represented on the system by the target SQL ID.

System Health Messages

Health syslog messages are sent every 10 minutes (at minute mod 10 boundaries). These messages are distinguished from event messages by the keywords cnt, sys, slowsys, and dbfwsys in the CEF Name field.

These messages contain a large amount of information helpful to DB CyberTech’ Technical Support personnel.

\<133>2018-06-11T03:44:44.797928-05:00 dbfw dbn: CEF:0|DB Networks|DBN|5.3.7|11|cnt|0| cs1Label=system identifier cs1=FW42-ED-VV-B-0423 system_identifier=FW42-ED-VV-B-0423 rt=1528706684797 xtime_T01=05/31/18 13:41:03 xtime_T02=06/11/18 03:44:44 xtime_T03=1 xtime_T04=10d 14:03:41 xtime_T05=06/01/18 15:48:54 xcap_X13=49460224 xcap_X01=49460224 xcap_X33=49460224 xcap_X03=6 xcap_X26=19 xcap_X27=61040 xcap_X28=61039 xcap_X04=1.00 xcap_X15=6 xcap_X11=1895 xcap_X21=0.01 xpro_X08=1 xpro_X17=1 xpro_X23=0.00 xpro_X24=0.00 xpro_X05=0.00 xpro_X09=0.00 xpro_X18=38287169 xpro_X19=1.00 xpro_X20=0.01 xpro_X35=406348 xpro_X36=8 xpro_X37=61019 xpro_X38=221101 xpro_X39=7046 xeng_X29=92 xeng_X30=19025081 xeng_X31=92 ts=1528706684796

As with event messages, the first part of the message contains the elements defined in the CEF format. Though most of the information in the various health log messages is useful only to DB CyberTech’ support personnel, there are a few fields you might want to track to ensure your system is running properly.

Event Message Fields That Users Should Track

Field Description
xcap_X13 Total number of packets received on the capture port. If this number is not increasing as expected for a given installation, the capture port might not be capturing traffic
xcap_X15 Total number of packets dropped by the engine. If this number increase rapidly, it might indicate that the span/tap port is configured to send a lot of non-sql traffic. This affects system performance and should be corrected either by changing the span/tap port configuration or adjusting the network filters on the DBC platform to filter out unwanted traffic before it reaches the engine.

The following messages are also sent every 10 minutes. These messages can be useful to DB CyberTech Technical Support and development personnel if an issue arises.

Typical sys (System) Message:

\<133>2018-06-11T03:49:47.332626-05:00 dbfw dbn: CEF:0|DB Networks|DBN|5.3.7|12|sys|0| cs1Label=system identifier cs1=FW42-ED-VV-B-0423 system_identifier=FW42-ED-VV-B-0423 rt=1528706987332 os_uptime=914936 os_loadavg_0=0 os_loadavg_1=0 os_loadavg_2=0 os_freemem=833536000 os_totalmem=8367423488 sys_user=1531705 sys_nice=9690 sys_system=744604 sys_idle=179829889 sys_iowait=30758 sys_irq=276608 sys_softirq=265033 sys_steal=0 sys_guest=0 sys_guest_nice=0 vm_pgpgin=931157 vm_pgpgout=105314097 vm_pswpin=0 vm_pswpout=0 vm_pgfault=542285262 meminfo_MemTotal=8171312 meminfo_MemFree=814000 meminfo_MemAvailable=3852672 meminfo_Buffers=355684 meminfo_Cached=2882872 meminfo_SwapCached=0 meminfo_Active=3055660 meminfo_Inactive=1970804 meminfo_Active(anon)=1816472 meminfo_Inactive(anon)=28444 meminfo_Active(file)=1239188 meminfo_Inactive(file)=1942360 meminfo_Unevictable=0 meminfo_Mlocked=0 meminfo_SwapTotal=976892 meminfo_SwapFree=976892 meminfo_Dirty=496 meminfo_Writeback=0 meminfo_AnonPages=1787968 meminfo_Mapped=2487416 meminfo_Shmem=71208 meminfo_Slab=179368 meminfo_SReclaimable=157068 meminfo_SUnreclaim=22300 meminfo_KernelStack=4256 meminfo_PageTables=31900 meminfo_NFS_Unstable=0 meminfo_Bounce=0 meminfo_WritebackTmp=0 meminfo_CommitLimit=5062548 meminfo_Committed_AS=4248612 meminfo_VmallocTotal=34359738367 meminfo_VmallocUsed=0 meminfo_VmallocChunk=0 meminfo_HardwareCorrupted=0 meminfo_AnonHugePages=0 meminfo_ShmemHugePages=0 meminfo_ShmemPmdMapped=0 meminfo_CmaTotal=0 meminfo_CmaFree=0 meminfo_HugePages_Total=0 meminfo_HugePages_Free=0 meminfo_HugePages_Rsvd=0 meminfo_HugePages_Surp=0 meminfo_Hugepagesize=2048 meminfo_DirectMap4k=157632 meminfo_DirectMap2M=8230912 memsum_usedGb=4 memsum_freeGb=4 disk_sda_readOps=37129 disk_sda_readSectors=1860258 disk_sda_writeOps=11382659 disk_sda_writeSectors=210640331

Typcial slowsys Message:

\<133>2018-06-11T03:49:51.565949-05:00 dbfw dbn: CEF:0|DB Networks|DBN|5.3.7|13|slowsys|0| cs1Label=system identifier cs1=FW42-ED-VV-B-0423 system_identifier=FW42-ED-VV-B-0423 rt=1528706991565 disk_root_total=47103168 disk_root_avail=36005372 disk_maint_total=2818080 disk_maint_avail=907268 disk_boot_total=194235 disk_boot_avail=79685 disk_sysdata_total=185301 disk_sysdata_avail=162649 vers=0 it_sysdecCommitted=0 it_sysdecProposed=0

Typical dbfwsys Message:

\<133>2018-06-11T03:49:49.338516-05:00 dbfw dbn: CEF:0|DB Networks|DBN|5.3.7|14|dbfwsys|0| cs1Label=system identifier cs1=FW42-ED-VV-B-0423 system_identifier=FW42-ED-VV-B-0423 rt=1528706989337 dbfw_pid=1884 dbfw_state=0 dbfw_userCpu=49031 dbfw_sysCpu=20857 dbfw_numThread=19 dbfw_VmSize=2761003008 dbfw_VmRSS=303161344

New Discovery Messages

New discovery syslog messages are sent when the DBC platform identifies a new user, service, host, listener, or context linking client and server in dimensions (ipseity).

These messages inform you when a new connection, user, service, host, listener, or context. has been added to the monitored network. The table below lists the critical information associated with the new discovery syslog messages.

New Discovery Syslog Messages

Signature ID Name Description
6 mds_new_user

  • user_name =<string = non-empty user name>

  • default_schema =<string = default schema for new user>
7 mds_new_service

  • service_name = <string = service_name>

  • service_name_type =<string =service type (service|SID|global name)>

  • dialect =<string = database dialect (Oracle|MS Sql)>
8 mds_new_host

  • realm =<string = realm name>

  • addr =<string =IPV4 address>
9 mds_new_listener

  • realm = <string = realm name>

  • addr = <string = IPV4 address>

  • port = <integer = TCP/IP port>
10 tally_new_ipseity

  • tally_board = <string = identifier for tally board, currently main>

  • [user_name = <string = non-empty user name>]

  • [service_name = <string = non-empty service name]

  • client_realm = <string = client realm name>

  • client_addr = <string = IPV4 addr of client>

  • server_realm = <string = server listener realm name>

  • server_addr = <string = IPV4 addr of server listener>

  • server_port = <int = TCP/IP port of server listener>

  • client_ipseities = <int = pre-existing ipseities with matching client host -- zero implies this is the first>

  • server_ipseities = <int = pre-existing ipseities with matching server host>.

  • [server_service_ipseities = <int = pre-existing ipseities with matching server host and service>]

  • [server_service_user_ipseities = <int = pre-existing ipseities with matching server host, service, and user>]

Sample new user message:

\<133>2018-06-11T13:50:00.449964-05:00 dbfw dbn: CEF:0|DB Networks|DBN|5.3.7|6|mds_new_user|5| cs1Label=system identifier cs1=FW42-ED-VV-B-0423 system_identifier=FW42-ED-VV-B-0423 rt=1528743000448 user_name=sa default_schema=sa

Sample new service message:

\<133>2018-06-11T13:50:00.441856-05:00 dbfw dbn: CEF:0|DB Networks|DBN|5.3.7|7|mds_new_service|5| cs1Label=system identifier cs1=FW42-ED-VV-B-0423 system_identifier=FW42-ED-VV-B-0423 rt=1528743000432 service_name=accounts service_name_type=service dialect=Sql-Server

Sample new host message:

\<133>2018-06-11T13:50:00.446950-05:00 dbfw dbn: CEF:0|DB Networks|DBN|5.3.7|8|mds_new_host|5| cs1Label=system identifier cs1=FW42-ED-VV-B-0423 system_identifier=FW42-ED-VV-B-0423 rt=1528743000444 realm=default addr=10.15.33.3

Sample new listener message:

\<133>2018-06-11T13:50:00.453014-05:00 dbfw dbn: CEF:0|DB Networks|DBN|5.3.7|9|mds_new_listener|5| cs1Label=system identifier cs1=FW42-ED-VV-B-0423 system_identifier=FW42-ED-VV-B-0423 rt=1528743000433 realm=default addr=10.3.30.14 port=14338

Sample new ipseity message:

\<133>2018-06-11T13:50:00.773763-05:00 dbfw dbn: CEF:0|DB Networks|DBN|5.3.7|10|tally_new_ipseity|5| cs1Label=system identifier cs1=FW42-ED-VV-B-0423 system_identifier=FW42-ED-VV-B-0423 rt=1528743000741 tally_board=main user_name=sa service_name=accounts client_realm=default client_addr=10.15.33.3 server_realm=default server_addr=10.4.40.7 server_port=1433 client_ipseities=1 server_ipseities=1 server_service_ipseities=1 server_service_user_ipseities=1

Audit Messages

Audit messages are an optional syslog output configured on the DBC platform under Settings > Advanced > Audit Log. The purpose of these messages is to provide a record of selected transactions on the DBN unit. The details of these messages are described below.

Sample audit message:

\<133>2018-06-11T16: 53:05 dbfw dbn: CEF:0|DB Networks|DBN|5.3.7|20|audit|0| cs1Label=system identifier cs1=FW42-ED-VV-B-0423 system_identifier=FW42-ED-VV-B-0423 rt=1528753985039 category=secOps auditCode=1009 auditMessage="User login succeeded" userId=admin sessionId=2CTvwhj_iAmVoV7zB8pVCiLSeALej0te src=10.40.7.216 target="User:admin" cookies="[{"name":"dbnetworks","cookieDurationSec":3600}]"

Audit syslog messages will have a category auditCode, auditMessage, userId, sessionId, and target when applicable.

Insider Threat Event Messages

The DBC platform sends insider threat syslog messages when the appliance sees statement executions that meet the criteria of an insider threat rule that has been configured to monitor and syslog. The purpose of these messages is alert customers to policy and stability violations in a monitored network. Insider threat rules are defined in terms of sets or patterns describing data flows.

A data flow is the unique combination of a partially or fully qualified table name (for example, “master.sys.databases” specifies database, schema, and relation, but not server) mentioned in a specific network context (i.e., client IP, server IP, server Port, database service, and database user). When a statement is executed, the DBC platform analyzes the SQL text semantically, looks up the corresponding data flow (or flows if there are more than one qualified name in the statement), and checks whether that flow meets the criteria of an insider threat rule. If the rule’s action is configured to write to syslog when it fires, the details of the data flow and unique identifiers for several aspects of the flow and rule are conveyed in messages described below.

The insider threat event module is made up of the following five types of events.

IT Clustered Flow

This event is emitted when the autopilot adds a data flow to the incident domain to be clustered with other behavioral incident data flows. Recall, each data flow is composed of a specific session and database object. The database object is one of relation, meta-relation, or user role. Relation and meta-relations are reported with an id, up to three name qualifiers (server, database, and schema) if applicable, a relation name, and mode of access (read or write for relations, create, drop, alter, or truncate for meta-relations). User role database objects are reported with an id, name, type (user or role), mode (create, drop, alter, grant, or revoke), when applicable a session database user ID and name, and when applicable, an optionally qualified relation. In addition to the defining features of the data flow in question, ITClusteredFlow events are characterized by the score information used by the autopilot to determine the data flow should be clustered.

Sample IT Clustered Flow message:

\<132>2018-06-11T13:50:00.773763-05:00 dbfw dbn: CEF:0|DB Networks|DBN|5.3.7|18|it_clustered_flow|7| cs1Label=system identifier cs1=FW42-ED-VV-B-0423 system_identifier=FW42-ED-VV-B-0423 it_event_id=1056 cluster_id=74 flow_id=1804 context_id=1800 user_id=300 user_name=BOB client_id=572 client_realm=default client_ip=10.1.41.11 service_id=1030 dialect=Oracle service_name=USCYBERCOM.OPSEC service_type=service listener_id=1028 listener_realm=default listener_ip=11.1.3.32 port=1521 context_earliest=1506003300000 access_id=317 relation_id=317 relation=personcreditcard mode=read access_earliest=1494273900000 flow_earliest=1506003300000 accessScore=0.999996204175 contextScore=0 combinedScore=0.999996204175 importance=1 risk=0.999996204175

Details of the field types:

Field Type Description
it_event_id int Event ID for new clustered data flow
cluster_id int Incident internal identifier for linking to DBN web interface
flow_id int Data flow internal identifier for linking to DBN web interface
context_id int Session internal identifier for linking to DBN web interface
user_id int Session database user name internal identifier
username string Session database user name (e.g., “BOB”)
client_id int Session client internal identifier
client-realm string Session client realm, typically “default” unless using VLANs in DBN configuration
client_ip string Session client IP address (e.g., “10.1.41.2”)
service_id int Session database service internal identifier
dialect string Session dialect description (e.g., “Oracle”)
service_name string Session database service name (e.g., “CRM.EU”)
service_type string Session database service type (“sid”, “global name”, or “service”)
listener_id int Session database listener internal identifier
listener_realm string Session database listener realm, typically “default” unless using VLANs in DBN configuration
listener_ip string Session database listener IP (e.g., “10.1.40.32”)
port type Session database listener port
context_earliest int Epoch milliseconds of earliest observed time for the data flow’s session
access_id int Database object internal identifier
relation_id int Database object relation internal identifier
meta_relation_id int Database object meta-relation internal identifier
server string Database object relation server qualifier
database string Database object relation database qualifier
schema string Database object relation schema qualifier
relation string Database object relation name
mode string Database object mode of use (e.g., “read” or “alter”)
user_role_id int Database object user role internal identifier
type string Database object user role type, either “user” or “role”
access_earliest int Epoch milliseconds of earliest observed time for the data flow’s database object
flow_earliest int Epoch milliseconds of earliest observed time for the data flow
access_score float Internal score for how unexpected the session is in the context of the data flow’s database object
context_score float Internal score for how unexpected the database object is in the context of the data flow’s session
combined_score float Internal score combining the access and context score
importance float User-specified weighting of the combined score
risk float Internal score combining combined score and importance

IT New Cluster

This event is emitted each time a new incident is created by the system. This occurs when new, unexpected data flows do not match an existing incident sufficiently. Either a new incident is created with the new data flow, or if the system’s clustering algorithms find a better grouping of unexpected data flows, old incidents are regrouped into new incidents to incorporate the new data flow

Sample IT New Cluster message:

\<132>2018-06-11T13:50:00.773763-05:00 dbfw dbn: CEF:0|DB Networks|DBN|5.3.7|22|it_new_cluster|7| cs1Label=system identifier cs1=FW42-ED-VV-B-0423 system_identifier=FW42-ED-VV-B-0423 itEventId=1047 cluster_id=127

Field Details:

Field Type Description
it_event_id int New incident event ID
cluster_id int New incident internal identifier for linking to DBN web interface

IT Obsolete Cluster

If the above-mentioned regrouping occurs, or if the user introduces either learning or policy constraints into the system, incident clusters of data flows can become obsolete. This event is emitted under those circumstances. It is disabled by default.

Sample IT Obsolete Cluster message:

\<132>2018-06-11T13:50:00.773763-05:00 dbfw dbn: CEF:0|DB Networks|DBN|5.3.7|23|it_obsolete_cluster|7| cs1Label=system identifier cs1=FW42-ED-VV-B-0423 system_identifier=FW42-ED-VV-B-0423 itEventId=1049 cluster_id=128

Field Details:

Field Type Description
it_event_id int Obsolete incident event ID
cluster_id int Obsolete incident internal identifier

IT Cluster Activity

This event is emitted when data flows, previously clustered into an incident exhibit activity (i.e., executing sql statements). Each event corresponds to a single data flow. The data flow is reported with the same fields defined used by the IT Clustered Flow event except the score specific fields, access_score, context_score, combined_score, importance, and risk. In addition, the following fields are supplied.

Sample IT Cluster Activity message:

\<132>2018-06-11T13:50:00.773763-05:00 dbfw dbn: CEF:0|DB Networks|DBN|5.3.7|24|it_cluster_activity|7| cs1Label=system identifier cs1=FW42-ED-VV-B-0423 system_identifier=FW42-ED-VV-B-0423 itEventId=1044 cluster_id=57 risk_type=high flow_id=1707 context_id=1672 user_id=301 user_name=system client_id=298 client_realm=default client_ip=10.1.41.3 service_id=1030 dialect=Oracle service_name=USCYBERCOM.OPSEC service_type=service listener_id=1028 listener_realm=default listener_ip=11.1.3.32 port=1521 context_earliest=1504451400000 access_id=480 relation_id=480 relation=customer mode=read access_earliest=1494377400000 flow_earliest=1504464600000 activity_earliest=1505986500000 activity_latest=1506747900000 execs=493

Field Details:

Field Type Description
it_event_id int New incident activity event ID
risk_type string Incident risk category (either “high” or “low”).
activity_earliest int Epoch milliseconds of the first observed time of activity for the data flow in this event
activity_latest int Epoch milliseconds of the latest observed time of activity for the data flow in this event
execs int Number of statement executions by the data flow in this event

IT Auto Learned

This event is emitted when a data flow is learned by the autopilot, using the same fields as the IT Clustered Flow event except clusterId. This event is also disabled by default.

Sample IT Auto Learned message:

\<132>2018-06-11T13:50:00.773763-05:00 dbfw dbn: CEF:0|DB Networks|DBN|5.3.7|18|it_auto_learned|7| cs1Label=system identifier cs1=FW42-ED-VV-B-0423 system_identifier=FW42-ED-VV-B-0423 itEventId=1056 flow_id=1804 context_id=1800 user_id=300 user_name=BOB client_id=572 client_realm=default client_ip=10.1.41.11 service_id=1030 dialect=Oracle service_name=USCYBERCOM.OPSEC service_type=service listener_id=1028 listener_realm=default listener_ip=11.1.3.32 port=1521 context_earliest=1506003300000 access_id=317 relation_id=317 relation=personcreditcard mode=read access_earliest=1494273900000 flow_earliest=1506003300000 access_score=0.999996204175 context_score=0 combined_score=0.999996204175 importance=1 risk=0.999996204175

For field details see IT Clustered Flow message detail.

IT Policy Activity

This event is emitted when data flows matching a committed policy constraint with a syslog category action exhibit activity (i.e., they execute sql statements). This event uses the same fields as the ITClusterActivity event, substituting constraint_id, category_id, and category for risk_type. The field details:

Field Type Description
It_event_id int New policy activity event ID
constraint_id int Internal identifier or policy constraint that matched the data flow for this event
category_id int Internal identifier for the category assigned to the constraint that triggered this event
category string Category name for the category assigned to the constraint that triggered this event

IT New Context

This event is emitted once for each new context (or session) the first time it is observed. A new session event has the following fields:

Field Type Description
context_id int Session internal identifier for linking to the DBN web management interface.
user_id int Session database user name internal identifier.
user_name string Session database user name (for example, “BOB”).
client_id int Session client internal identifier.
client_realm string Session client realm (typically “default” unless using VLANs in DBN configuration).
client_ip string Session client IP address (for example, “10.1.41.2”).
service_id int Session database service internal identifier.
dialect string Session dialect description (for example, “Oracle”)
service_name string Session database service name (for example, “CRM.EU”).
service_type string Session database service type (“sid”, “global name”, or “service”).
listener_id int Session database listener internal identifier.
listener_realm string Session database listener realm (typically “default” unless using VLANs in DBN configuration).
listener_ip string Session database listener IP address (for example, “10.1.40.32”).
port type Session database listener port.
context_earliest bigint Epoch milliseconds of earliest observed time for the data flow’s session.

IT New Access

This event is emitted once for each new access, also referred to as database object, the first time it is observed. A database object is one of relation, meta-relation, or user role. Relation and meta-relations are reported with:

  • An id

  • Up to three name qualifiers (server, database, and schema) if applicable

  • A relation name

  • A mode of access

  • For relations, this can be read or write.

  • For meta-relations, this can be create, drop, alter, or truncate.

User role database objects are reported with an id, name, type (user or role), mode (create, drop, alter, grant, or revoke), when applicable a session database user ID and name, and when applicable, an optionally qualified relation. A new object event has the following fields.

Field Type Description
access_id int Database object internal identifier.
relation_id int Database object relation internal identifier.
meta_relation_id int Database object meta-relation internal identifier.
server string Database object relation server qualifier.
database string Database object relation database qualifier.
schema string Database object relation schema qualifier.
relation string Database object relation name.
mode string Database object mode of use (for example, “read” or “alter”).
user_role_id int Database object user role internal identifier.
user_role_name string Database object user role name.
type string Database object user role type (either “user” or “role”).
access_earliest bigint Epoch milliseconds of earliest observed time for the data flow’s database object.

IT New Flow

This event is emitted once for each new data flow, the first time it is observed. A data flow is the unique combination of a context (also referred to as session) and access (also referred to as object). The fields for a new flow event are those used for a new context, those used for a new access, and also the following.

Field Type Description
flow_earliest bigint Epoch milliseconds of earliest observed time for data flow.

CMDB Key-Value Pairs Format

The tally_new_ipseity (10), it_clustered_flow (18), it_cluster_activity (24), it_auto_learned (25), and it_policy_activity (26) events can be extended with CMDB data. The current implementation adds CEF pairs for each user extension of user, service, client, and relation (for example, table) that has the syslog flag (1) set and applies to the event in question. For example, tally_new_ipseity events do not have relation attributes to extend, but the IT events do.

Every custom message key is prefixed by an identifier for the scope of attribute being annotated, followed by the name of the annotation. For example, if there exists CMDB data annotating each service with a risk_score and a division, the tally_new_ipseity custom pairs resembles mds.services_riskScore=34 and mds.services_division=HR.

The tally_new_ipseity events have the following prefixes:

  • User annotations will be prefixed by mds.users_

  • Service annotations will be prefixed by mds.services_

  • Client host annotations will be prefixed by mds.hosts_

The IT events have the following prefixes:

  • User annotations will be prefixed by user_ext_mds.users_

  • Service annotations will be prefixed by service_ext_mds.services_

  • Client host annotations will be prefixed by client_ext_mds.hosts_

  • Relation annotations will be prefixed by relation_ext_parser.relation_

logo

DB CyberTech

15015 Avenue of Science

Suite 150

San Diego, CA 92128

http://www.dbcybertech.com
